Orbsmart AW-15 Mini PC

The Orbsmart AW-15 is a Mini PC of the latest generation based on Windows™ 11 Pro in a compact & fanless case. The latest processor generation Intel™ “Alder Lake” is used with the quad-core N100 plus 16GB RAM and a fast 256GB SSD.

The system also offers sufficient performance for intensive programs and can be used universally for many areas of application, e.g. as an Office-PC, mediacenter or streaming box or in the professional sector as a thin client or workstation.

  • Perfect as an energy-saving Office-PC, Streaming Mediaplayer and much more
  • Fanless case with ultra low power consumption / Autostart + WOL + PXE + RTC support
  • Windows 11 Professional operating system pre-installed
  • Current Intel Quad Core “Alder Lake-N” N100 CPU / 16GB DDR4 RAM / 256GB SSD
  • HDMI 2.0, mDP 1.2 & VGA / 1x USB 3.1 Type-C + 2x USB 3.1 + 2x USB 2.0 / 3.5mm Audio
  • WIFI 6 (Dual band 2.4/5GHz) / Bluetooth 5.2 / 2.5-GBit LAN
  • Intel N100 “Alder Lake-N” quad core
  • Intel UHD Graphics XE (24 EUs, Burst freq: 750 MHz)
  • 16GB SODIMM DDR4-RAM
  • 256GB SSD (M.2 NVMe 2280)
  • Windows 11 PRO 64-bit (pre-installed)
  • WIFI 6 – 802.11b/g/n/ac/ax (2.4/5 GHz)
  • Bluetooth 5.2
  • 1x HDMI 2.0
  • 1x VGA
  • 1x Mini-DP 1.2
  • 1x USB 3.1 Type-C (Gen1)
  • 2x USB 3.1 (Gen1)
  • 2x USB 2.0
  • 1x RJ45 2.5 GBit LAN
  • 1x 3.5mm audio (combo)
  • 1x micro-SD slot
  • 1x M2. NVMe SSD B-Key (2242)
  • Dimensions: 13 x 13 x 4 cm
  • Weight: 465g

Where to buy

Fanless – compact – energy efficient

The Orbsmart AW-15 is a Windows 11 mini PC with extremely compact dimensions (13 x 13 x 4 cm). The case has a high-quality build and the passive and completely fanless cooling allows for absolutely silent operation. The power consumption is only a few watts even under full load. This energy-efficient mini PC makes it possible to reduce ongoing electricity costs and scores in the area of sustainability at the same time.

Alder Lake

The AW-15 uses the latest Intel chip generation “Alder Lake-N” with the powerful quad-core Intel™ N100 processor (burst freq: 3.40 GHz) plus 16GB DDR4 RAM working memory. The performance offers more than enough power reserves even for demanding office applications, surfing or smaller games. You also have a fast 256GB SSD (NVMe)  for storage.

Windows™ 11 Professional

A Windows 11 Professional (64-Bit) version is already pre-installed as the operating system. You can start right away, all drivers and the German & English language pack are pre-installed. The AW-15 turns any monitor or TV into a Windows 11 All-in-One PC. All programs supported by Windows 11, such as Chrome, Microsoft Office/Teams, KODI, Thunderbird, TeamViewer, Skype & Co can be used without problems.

Extremely versatile

Thanks to Windows 11, there are almost no limits when it comes to possible uses: ideal as an Office-PC (Microsoft Office, Zoom, Skype), streaming PC (YouTube, Prime Video, Netflix, Skygo, DAZN, Disney+ & Co.), media player (KODI Mediacenter, PLEX etc.) or in the professional field for companies in continuous operation (display system/digital signage, thin client, automation, workstation, server).

4K ULTRA HD

Resolutions up to 2160p (60 Hz) are supported by the Orbsmart Windows Computer thanks to the integrated HDMI™ 2.0 and/or Mini DisplayPort 1.2 connector. Enjoy streaming services, videos or pictures in ultra-high definition quality – no need to buy an additional computer. In addition, a third monitor can be connected via VGA.

Triple Display

Besides the HDMI and Mini DisplayPort, a VGA port is also built into the case (VGA cable not included). This allows up to three monitors to be used simultaneously as an additional display.

Expandable

The AW-15 allows the installation of an additional M.2 SATA SSD (2242). The base plate can be removed without additional tools. The storage space can thus be expanded without an additional external USB hard drive or micro-SD card.

USB 3.1

With this mini PC box, three USB 3.1 ports are freely available. One of them is already a modern USB 3.1 Type-C port (only for data exchange & power supply). Basically, any mouse/keyboard, air mouse, USB stick/hard drive or DVD/BD drive can be connected without any problems.

2.5 Gbit LAN

As one of the few mini PCs on the market, the Orbsmart AW-15 has a fast 2.5 Gbit LAN port (incl. IEEE1588/PTP support). This enables an extremely high data rate for fast file downloads or smooth streaming of movies in high resolution.

WIFI 6 + BT 5.2

The external WIFI antenna (Dual band 2.4/5 GHz) with WIFI 6 / AX standard provides high range and data rates. Additional devices (for example mouse/keyboard, headset) can be connected via wireless Bluetooth 5.2 technology. Alternatively, the Gigabit LAN port provides a stable connection to your router or home network. The AW-15 is also perfect as a streaming media player.

Mounting kit included

Ready to go: the AW-15 offers a wide range of accessories. In addition to an HDMI 2.0 cable, EU power supply and manual (German/English), a mount for a TV/monitor (VESA 75×75 / 100×100) is also included.

Benchmarks / comparison table

Orbsmart AW-15 (Intel N100 - Passmark Average CPU: 5578)
Orbsmart AW-14 (Intel Celeron N5105 - Passmark Average CPU: 4058)
Orbsmart AW-12L (Intel Celeron J4125 - Passmark Average CPU: 3047)
Product

Orbsmart AW-12L

Orbsmart AW-14

Orbsmart AW-15

Operating systemWindows 11 ProfessionalWindows 11 ProfessionalWindows 11 Professional
Processor / GPU Quadcore Intel Celeron “Gemini Lake Refresh” J4125 (@2.00 GHz / Burst freq: 2.70 GHz) / Intel HD Graphics 600Quadcore Intel Celeron “Jasper Lake” N5105 (@2.00 GHz / Burst freq: 2.90 GHz) / Intel UHD GraphicsQuadcore Intel Celeron “Alder Lake-N” N100 (@0.80 GHz / Burst freq: 3.40 GHz) / Intel UHD Graphics XE
Working memory / Int. Memory 8GB DDR4 RAM / 128GB internal memory16GB DDR4-RAM + 256GB SSD16GB DDR4-RAM + 256GB SSD
Connections2x HDMI 2.0,1x Gigabit-LAN, 4x USB 3.0, 1x 3.5mm audio, microSD slot1x HDMI 2.0, 1x VGA, 1x DP 1.2, 1x Gigabit LAN, 1x USB 3.1 (Gen1) + 1x USB 3.1 Type-C (Gen1), 2x USB 2.0, 1x 3.5mm audio, microSD slot1x HDMI 2.0, 1x VGA, 1x DP 1.2, 1x 2.5 Gigabit LAN, 1x USB 3.1 (Gen1) + 1x USB 3.1 Type-C (Gen1), 2x USB 2.0, 1x 3.5mm audio, microSD slot
WIFI / Bluetooth 802.11b/g/n/ac (2.4/5GHz) / Bluetooth 4.2802.11b/g/n/ac/ax (2.4/5GHz) / Bluetooth 5.2802.11b/g/n/ac/ax (2.4/5GHz) / Bluetooth 5.2
Maximum resolution 4K Ultra HD (max. 60Hz) 4K Ultra HD (max. 60Hz)4K Ultra HD (max. 60Hz)
2.5″ hard disk slot NoSATA (max. 9.5mm)No
M.2 SSD slot YesYes (2280 occupied / 2242 free)Yes (2280 occupied / 2242 free)
